The leading manufacturer and service provider of CNC router machines in various categories such as - CNC Router Machine, CNC Stone Engraver Machine, CNC Glass-Cutting, and CNC Router with Rotary machines and other solutions since 2012.
| Spec | Detail |
|---|---|
| Outer Dimensions | 2210 x 3200 x 1600 |
| Working Area (X, Y, Z) | 1300 x 2500 x 210 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Spindle | AIR COOLED 3.5KW-6KW /Water cooled 2.2KW-5.5KW |
| Spindle Speed | 18000/24000 RPM |
| Maximum Travelling Speed | 18 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | STEPPER |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | ALLUMINIUM T SLOT/VACCUM BED |
| Spec | Detail |
|---|---|
| Outer Dimensions | 2210 x 3200 x 1600 |
| Working Area (X, Y, Z) | 1300 x 2500 x 210 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Spindle | AIR COOLED 3.5KW-6KW /Water cooled 2.2KW-5.5KW |
| Spindle Speed | 18000/24000 RPM |
| Maximum Travelling Speed | 30 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | EASY SERVO |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | ALLUMINIUM T SLOT/VACCUM BED |
| Spec | Detail |
|---|---|
| Outer Dimensions | 2210 x 3200 x 1750 |
| Working Area (X, Y, Z) | 1300 x 2500 x 210 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Spindle | AIR COOLED 3.5KW-6KW /Water cooled 2.2KW-5.5KW |
| Spindle Speed | 18000/24000 RPM |
| Maximum Travelling Speed | 40 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | AC SERVO |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | ALLUMINIUM T SLOT/VACCUM BED |
| Spec | Detail |
|---|---|
| Outer Dimensions | 2210 x 3200 x 1600 |
| Working Area (X, Y, Z) | 1300 x 2500 x 210 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Spindle | AIR COOLED 3.5KW-6KW /Water cooled 2.2KW-5.5KW |
| Spindle Speed | 18000/24000 RPM |
| Maximum Travelling Speed | 18 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | STEPPER |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | SS BED WITH ALLUMINUM T SLOT |
| Spec | Detail |
|---|---|
| Outer Dimensions | 2210 x 3200 x 1600 |
| Working Area (X, Y, Z) | 1300 x 2500 x 210 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Spindle | AIR COOLED 3.5KW-6KW /Water cooled 2.2KW-5.5KW |
| Spindle Speed | 18000/24000 RPM |
| Maximum Travelling Speed | 30 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | EASY SERVO |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | SS BED WITH ALLUMINUM T SLOT |
| Spec | Detail |
|---|---|
| Outer Dimensions | 2210 x 3200 x 1750 |
| Working Area (X, Y, Z) | 1300 x 2500 x 210 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Spindle | AIR COOLED 3.5KW-6KW /Water cooled 2.2KW-5.5KW |
| Spindle Speed | 18000/24000 RPM |
| Maximum Travelling Speed | 40 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | AC SERVO |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | SS BED WITH ALLUMINUM T SLOT |
| Spec | Detail |
|---|---|
| Outer Dimensions | 1310 x 1300 x 1600 |
| Working Area (X, Y, Z) | 600 x 900 x 100 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Maximum Travelling Speed | 18 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | STEPPER |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | VACCUUM TABLE |
| Spec | Detail |
|---|---|
| Outer Dimensions | 1310 x 1300 x 1600 |
| Working Area (X, Y, Z) | 600 x 900 x 100 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Maximum Travelling Speed | 30 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | EASY SERVO |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | VACCUUM TABLE |
| Spec | Detail |
|---|---|
| Outer Dimensions | 1310 x 1300 x 1600 |
| Working Area (X, Y, Z) | 600 x 900 x 100 |
| Linear Guidways | 20MM/25MM |
| Axis Drive system | x,y axis - RACK & PINION AND z -BALL SCREW |
| Maximum Travelling Speed | 40 MTR/MIN |
| Operating System | DSP /NC STUDIO |
| Driving System | AC SERVO |
| Power Supply | AC 415V/50Hz, 3 Ø/ AC 240V/50HZ 1Ø |
| Working table | VACCUUM TABLE |
CEO & Founder
Cheif Engineer & Finance Manager
Mechanical Engineer
Our state-of-the-art technology ensures precision and quality in every carving. Our CNC machines are equipped with advanced features and cutting-edge software that enable intricate designs, fine detailing, and consistent accuracy, giving our customers the confidence that their wood carving projects will be executed to perfection.
The production plants can be visited, with guided tours that help to better understand the production processes. We are always open to customers who wish to view the machines, participate in demonstrations and review feasibility studies and performance test results.
We focus on maximizing value while minimizing waste within an our processes. We create more value for customers with fewer resources and less time.
We strive to achieve sustainable improvement in key performance metrics, such as efficiency, quality, cost, delivery, and customer satisfaction.
Customers can reach out to us for assistance at any hour, day or night, regardless of time zone differences.
Out products consistently outperforms its peers in terms of quality, efficiency, reliability, customer satisfaction, or other relevant metrics.
